特点：

额定电流(In)                                       : 300A.t rms(额定值)

测量范围                                            : 0~±600A.t(DC~AC Peak)

测量阻值(在70℃)                              : Rm min         Rm max

with±18V, at±300 A.t Max               :  0ohm           70ohm

模拟输出电流(在300A时)                 : 150mA

匝数比率                                            : 1/2000

精度(25℃)                                          : 优于±0.5%In

供电电压                                            : ±12~18VDC(±5%)

原副边电气绝缘                                : 7.5KVrms/50KHz/1分钟
